Short answer: This guide sorts Rad models into three groups. The list credits Area 13 Ebikes' published testing, and we could re-check only part of it, so confirm your model and year with the kit seller. Listed as a direct fit: 2016–2018 RadRover and 2019–2021 RadRover up to Rover 5. Needing mounting or wiring work: RadCity, older RadWagon, Runner, RadExpand 5 (cadence version), Mission and Runner Two/Plus. Not compatible: Rover 6, RadWagon 5 and bikes with the newer 500-lumen headlight system.
Rad Power Bikes went through Chapter 11 in late 2025, and although the brand now operates under a new owner, its official parts store does not currently sell controllers. For owners the question that follows is a practical one: when the controller on your bike fails, can you fit an aftermarket kit instead of hunting for an original part? The honest answer is that it depends on which model you own and roughly which year it was built. For some bikes the answer is a straight no, and knowing which group yours falls into before you spend money is the whole game.
The short answer, by model
Compatibility here follows the testing published by Area 13 Ebikes, who build KT-based upgrade kits for Rad bikes around a 35A controller paired with an LCD8H display. Their results sort the range into three groups.
Fits without modification: the 2016–2018 RadRover, and the 2019–2021 RadRover up to Rover 5.
Fits, but needs work: RadCity, the older RadWagon, Runner, RadExpand 5 in the cadence-sensor version only, Mission, and Runner Two/Plus. Installation is possible on these, but plan on adapting the mounting or the wiring rather than swapping one part straight across.
Not compatible: Rover 6, RadWagon 5, and any bike running the newer 500-lumen headlight system.
The three groups at a glance
| Group (as listed in this guide) | Models | What to expect |
|---|---|---|
| Listed as a direct fit | 2016–2018 RadRover; 2019–2021 RadRover up to Rover 5 | Installation may still need adjusting. Area 13's own kit notes call 2016–2018 RadRovers plug and play, but the 2020 RadRover ST in CleanTechnica's install review still needed a modified mount, so measure the space |
| Listed as needing work | RadCity, older RadWagon, Runner, RadExpand 5 (cadence-sensor version only), Mission, Runner Two/Plus | Plan on adapting the mounting or the wiring. Area 13's older kit notes say it had not tested RadCity or RadWagon itself and was going on customer reports |
| Listed as not compatible | Rover 6, RadWagon 5, any bike with the newer 500-lumen headlight system | Integrated controller and proprietary harness; read the headlight warning further down before trying anything |
Unplug, reseat and inspect connectors with the bike switched off and the battery removed. Reconnect the battery and switch on only for the steps that need power, such as reading the code, a voltage reading, a reset or testing the throttle and pedal assist, and switch off again before you touch the next plug. A controller kit replaces the controller, display and harness together, so plan the whole job before you start.
Why 2021 is roughly the dividing line
Earlier Rad bikes used a conventional layout: a controller in its own housing, wired out to the motor, display and battery through connectors that follow patterns the wider industry also uses. Later bikes went the other way. The controller became integrated into the frame, and the battery compartment and harness are proprietary. Once a manufacturer builds it that way, a third-party controller has nowhere to physically live and nothing standard to plug into. That is the structural reason Rover 6 and RadWagon 5 sit on the "no" list rather than the "difficult" list — it is not a matter of trying harder.
The headlight worth a paragraph of its own
One warning deserves separating out: the 500-lumen headlight system on newer Rad bikes can destroy an aftermarket controller. If your bike has that lighting system, treat the bike as incompatible rather than looking for a way to work around the light.
Size is a real constraint, not a detail
A kit controller is not necessarily the size of the part it replaces. The Area 13 unit measures 7.5 by 3.25 by 1.75 inches, which is larger than the original controller on several models. On those bikes it will not drop into the factory controller location, and you will need to fabricate a bracket to mount it. Measure the cavity you have before ordering, not after the box arrives.
Why the display goes with it
A controller swap is really a communication problem, on any brand. KT controllers speak the KT protocol and pair with KT displays such as the SW900 and the LCD8H family; a display from another protocol family will not talk to them. Three rules make this messier than it first looks. Same model number does not guarantee the same protocol, because firmware versions differ and some displays can be switched between protocols through a parameter setting. Same brand does not guarantee compatibility either, for the same reason. And a connector that plugs in with a screen that lights up proves nothing about the data link — a lit display can still fail to read speed or change assist levels.
That is why these parts are sold as matched kits, with controller, display and harness tested together, instead of as separate pieces. We have written about the same problem seen from the display side, and about what the wire colours on a controller harness actually tell you.
Three numbers to check before ordering
Whatever your model, three electrical figures have to line up. Voltage must be the same across battery, controller and motor. Current matters in both directions: the controller's rated current has to stay within what your battery can deliver continuously, and reach what the motor asks for. Power follows from that — a controller rated below the motor's rated wattage will lose speed on hills and can fail outright.
A digital multimeter confirms the voltage side of that check, and the same three figures apply to any replacement controller you compare.
Common questions
Can I fit an aftermarket controller to a Rover 6 or RadWagon 5?
Not according to the list in this guide, which we could not fully re-check. On those bikes the controller is integrated into the frame and the battery compartment and harness are proprietary, so a third-party controller has nowhere to physically live and nothing standard to plug into.
Why does the display have to change with the controller?
Because the controller and display talk to each other over a protocol, and a display from another protocol family will not talk to the controller even when the plug fits. Area 13's kit, for example, pairs its controller with an LCD8H color display (see Area 13's own kit notes), which is why these parts are sold as matched kits with the controller, display and harness tested together.
Will the kit controller fit where the original one was?
Not always. The Area 13 unit measures 7.5 by 3.25 by 1.75 inches, which is larger than the original controller on several models, so measure the cavity and be ready to fabricate a bracket.
What the new owner sells today
Life Electric Vehicles completed its purchase of Rad's assets in early March 2026, and Rad's own store sells bikes and spare parts again. As of October 2026, those spare parts are batteries, chargers, lights, tires, brake parts and similar items; no controllers, displays, throttles, sensors, wiring harnesses or motors are listed. That could change, so check Rad's spare-parts page before you buy an electrical part anywhere else.
Placing your own bike
Start with the model and model year, then look at the bike itself: is the controller a separate housed unit, or built into the frame? Does it have the 500-lumen light? Will the replacement physically fit the space? If you are replacing a wheel or hub motor in the same project, dropout width becomes a fourth question — fat-tire builds in this class settle on either 170 mm or 190 mm, and those are not interchangeable, so measure the frame instead of assuming. For the wider picture on sourcing the parts Rad's own store does not carry, see our guide to where to get Rad replacement parts.
Once you know which part has failed, compare e-bike spare parts by connector and pin count rather than by bike name.
This guide is part of our Rad Power Bikes repair guide, and the full job is laid out in how to replace an e-bike controller. Related: Rad error codes, what more controller current costs your motor and battery and why displays are not interchangeable.
Last updated November 4, 2026: added a short answer, a compatibility table with source links and answers to common questions. The model groups are unchanged.
